Football/Soccer Goals

Soccer Goals Diagram

PRODUCT CODE GOAL SIZE A Width (metres) B Height (metres) C OD Diameter (millimetres) Wall Thickness (millimetres)
MS – 38 JUNIOR 6.0 2.0 120 3.0
MS -39 SENIOR 7.32 (8 YARDS) 2.44 (8 FEET) 120 3.0

Specifications:

  • 1 x set of goals include: 4 x upright posts, 2 x crossbars, 4 x ground tubes (ie. Both ends of pitch)
  • Manufactured from 6061 T6 high-tensile marine grade aluminium tube
  • UV-stabilised heavy duty white powder coat finish to Australian Standards AS4506-2005
  • Each goal consists of and dismantles down into the three separate section pieces, (2 x upright posts, and 1 x crossbar), makes for safer and easier manual handling also more compact for storage
  • One-piece crossbar (manufactured from a single full length tube section) for maximum crossbar rigidity and structural strength
  • Crossbar corner joint connection plugs are manufactured from UV-stabilized solid HDPE (High Density Polyethylene) with 12.7 mm stainless steel hex head attachment bolts
  • Hot dipped galvanised steel spigots fitted with HDPE machined bushes
  • 6061 T6 high-tensile marine grade aluminium ground tubes with stainless steel security locking screws below ground level
  • Machined solid nylon ground tube cap plugs
  • Utilises our spigot base and ground tube sleeve footing system

In ground footing with ground tube system (the goals are re-moveable if required in the off-season, where grounds are utilised for multiple sports codes throughout the year or semi – permanent)

  • Engineering Certification in accordance with AS1170.2 & AS1170.4
